Lubricating Front Axle

NOTE: Lubricate every 250 hours under normal conditions.

Apply several shots of grease to each fitting when operating tractor in extremely wet or dusty conditions.

Use John Deere High-Temperature/Extreme Pressure/Non-Clay grease.

A-Steering Cylinder Ends
B-Tie Rods
C-Steering Spindles
D-Axle Pivot Pin

AG,RF30435,2531 -19-21DEC99-1/1
