Setting Hitch Height Limit

RXA0082725


A-Height/Rate Switch
B-CommandCenter Display


C-Height Bargraph
D-Command Dial


E-Hitch Position Indicator


F-Select Switch

Hitch height limit is adjusted in the CommandCenter.

1. Press Height/Rate Switch (A) once and observe Display (B); current height setting appears as a bargraph (C) on left-hand side.

2. Turn Command Dial (D) counterclockwise to lower height limit setting; clockwise to raise setting.

Changes to height setting take place immediately. Lowest height setting is limited to 25% of maximum height. Indicator (E) shows current hitch position.

3. When desired height is observed, press Select Switch (F) to return to previous display.

OU1092A,0000405 -19-28JUL05-1/1
