IMS Functions-AutoPowr TransmissionAutoPowr Set Speed: The current forward set speed (FSS1 or FSS2) can be changed up or down with the set speed adjuster (C), during Learn mode. Transmission ratio changes will be executed at the normal rate once the set speed has been changed. During Learn mode, the set speed may be changed more than once. IMS will record the time of the first set speed change in the sequence. If additional changes occur at less than two second intervals, they will be combined with the first into a single event. The direction of the set speed change (up or down), the speed control lever (D) position (speed band 1 [A] or 2 [B]), and the final set speed are recorded. If the speed control lever is moved while learning a sequence, the set speed changes will not be saved. The minimum set speed that can be saved is 1.5 km/h (0.93 mph). Changing the set speed or moving the lever during execution of a sequence will not cause IMS to abort, but set speed changes will not be commanded for the remainder of the sequence. During execution of a learned sequence, IMS will not change the set speed unless the lever is in the learned speed band (1 [A] or 2 [B]). If the lever is not in the learned speed band during execution of a sequence, IMS will not abort the sequence, but set speed changes will not be commanded for the remainder of the sequence. During execution of a learned sequence, IMS will not change the set speed in the opposite direction from what was learned in order to reach the desired set speed. For example, if the set speed adjuster (C) is turned down to reach 7.0 km/h (4.35 mph) during Learn mode, IMS records when the change occurred, the direction of change (down), the speed band, and the final set speed (7.0 km/h [4.35 mph]). If the set speed is 6.0 km/h (3.73 mph) when execution of the sequence begins, IMS will not change the set speed to 7.0 km/h (4.35 mph). When a set speed is changed by IMS, the controller will react just as if the operator changed the set speed, pushing other set speeds up or down as a result. |
|
