Setting Rear PTO Engagement Rate

1. Select PTO.


   RXA0104058-UN-22JUL09

   PTO Short Cut Button


   RXA0104056-UN-22JUL09

   PTO Page


   RXA0104057-UN-22JUL09

   PTO Advanced Page

   A - FieldCruise Setting Softkey

   B - Advanced Settings Softkey

   C - FieldCruise Settings Box

   D - FieldCruise On/Off Softkey

   E - FieldCruise On/Off Check Box

   F - Drop Down Box

   NOTE: When FieldCruise™ setting softkey (A) is selected FIELDCRUISE settings box (C) is highlighted. Using thumb wheel engine rpm can be adjusted.

---




2. Rotate thumb wheel forward to increase or rearward to decrease engine rpm.

3. Select FIELDCRUISE On/Off softkey (D). Check mark in FIELDCRUISE settings box (E) will indicate FIELDCRUISE is ON (checked) or OFF (unchecked).

   NOTE: PTO advanced settings page will display the current PTO engagement rate.

4. Select PTO Advanced softkey (B).

   NOTE: Drop down box will offer 3 options; Auto, Low Rate and High Rate.

5. To change PTO engagement rate, click on double arrow in drop down box (F).

6. Using thumb wheel, scroll to rate needed and press Confirm button.
