Crop Divider Float Reset Switch

CQ282608-UN-10MAR09

Turning ON floating mode:

1. Depress Crop Divider Float Reset switch located on armrest. When the float mode is armed and ready to use, the green light in the switch will be illuminated.

2. Depress the right or left crop divider down button on the joystick. If the operator desires both crop dividers in the float mode, both crop divider down buttons need to be depressed.

Turning OFF floating mode:

Depress the up button for the crop divider you desire to work in the normal mode or depress the reset switch again which will terminate both divider and set them back to the normal mode.

NOTE: It's recommended to have crop dividers in their lowest position prior to activating the float mode.
