Harvesting Function Quick Stop Switch

CM023500010-UN-07FEB05

When this switch is set to the down position, the switch will light up and all harvesting functions will stop. Setting the switch to the upper position and activating the reset switch, engages the harvesting functions again, if the operator is seated. If the operator stands up for longer than 5 seconds all harvesting functions will stop and the harvesting function stop switch will light up. The operator will have to sit back down and engage the reset switch for the harvesting functions to start up again.
