CC9157-UN-23SEP98
A - Cam
B - Pin
Remove pin (A) from gear.
Pull out billhook and remove cam (B).
Install cam, billhook, washers, gear, and pin.
NOTE: End play must be 0—0.38 mm (0—0.015 in.).
OUCC002,0002317-19-20100319
