Coolant Temperature Indicator Light

Lights up if coolant temperature exceeds 108°C (226°F) and/or if the charge air temperature exceeds 88°C (190°F).

- Run engine without load for a short period. If temperature will not drop, stop engine and remedy the fault.

AG,CO03622,1401 -19-13MAR02-1/1
