Threshing Cylinder Indicator Light

Lights up if threshing cylinder speed drops more than 25% of the adjusted speed.

- Reduce ground speed.

With Engine Shut Off and Separator Stopped:

- Check drive.

- Check for plugging.

- Check alarm speed. Readjust, if necessary (see instructions in this Section).

AG,CO03622,1411 -19-05NOV02-1/1
