Tires

In addition to wearing rapidly, an underinflated tire can slip on the rim and cut the valve stem.

See "Wheels, Axles and Additional Weights" Section for the correct pressure.


A-Pressure Too Low
B-Pressure Too High
C-Correct Pressure

ZCQD1100

AG,CO03622,1506 -19-17MAY02-1/1
