Vacuum System Shutdown

LX1015612-UN-08JAN97

L32200-UN-13APR00

A - Lowered

B - Raised

C - Neutral lever position

D - Float position

E - Locking

Follow steps below to switch off vacuum system on John Deere tractors:

1. Set lever on tractor to float position (D) until turbine comes to a full stop.

2. After turbine stops, lever must be placed in neutral position (C).

IMPORTANT: Vacuum system should operate in tractor lever position (A).

NOTE: This procedure will help to preserve turbine hydraulic system.
