Starting the Engine

Multi-Function Control Handle

Move multi-function control handle (A) to neutral position.

CQ278220

OU64006,00000A5 -19-25AUG06-1/3

Starting

causym CAUTION: Always sound the horn before starting the engine. This warns other persons standing close to the combine and avoids possible accidents.

Insert key switch and turn it clockwise to position (D) to start up engine.

If engine does not start, repeat procedure once. If it still does not start, wait for two minutes before you try again. This will preserve the battery.

CQ265670
CQ269140

OU64006,00000A5 -19-25AUG06-2/3

Warming Up

Run the engine at half throttle for approximately 2 to 4 minutes.

CQ176740

OU64006,00000A5 -19-25AUG06-3/3
