Check Engine Oil Level

1. Park tractor on flat and level terrain. Withdraw dipstick , oil level should be between the two marks on dipstick (A). Do not operate the engine if oil level is below minimum mark.
2. If below, add oil through filler neck (B) until full.

Check oil level with dipstick.

Use John Deere SAE 15W-40 oil.

AG,LT04177,261 -19-13MAR06-1/1
