Threshing Cylinder Indicator Light

Lights up if threshing cylinder speed drops more than 25% below adjusted speed.

Cab buzzer sounds with priority 2. See "Cab Alarm Priorities".

- Reduce speed.

With engine shut off and separator stopped:

- Check drive (belts).

- Check for plugging.

- Check speed alarm. Readjust if necessary (see instructions in this section ).

AS60558,0001172 -19-02FEB09-1/1
