Straw Walker Indicator Light

Lights up if straw walker shaft speed drops more than 10% below rated speed.

Cab buzzer sounds with priority 2. See "Cab Alarm Priorities".

With engine shut off and straw walkers stopped:

- Check drive (belts).

- Check for plugging.

AS60558,0001175 -19-02FEB09-1/1
