Access the Engine Compartment

1. IMPORTANT:


   T8T2430-UN-24APR15

   Right-Hand Side Of Machine Shown

   A - Latch

   B - Door

   C - Door Lock

   Engine cannot be started when left-hand engine compartment door is open.

   If engine is running, opening left-hand door shuts OFF engine.

   Open latch (A) to release engine compartment door (B).

---




2. Open door, pull door lock (C) upwards, and swing lock into hole in door.
