Connecting Baler Wiring Harness to Tractor

1. Route baler wiring harness into tractor operator's platform/station.

2. Connect baler wiring harness to BALETRAK PLUS ® monitor-controller harness connector. Line up timing mark on connectors and tighten locking ring. Monitor-controller power plug is connected to tractor convenience outlet.

E40554

BALETRAK PLUS is a registered trademark of Deere & Company

AG,OUO6017,1606 -19-03NOV99-1/1
