Wheel Spindle Positions 31 x 13.5-15 Tires-Wide Pickup (456/456S)

Normal position (A) is recommended for most baling conditions.

• Recommended with bale ramp.
• Pickup teeth may not touch the ground with pickup completely lowered depending on tractor drawbar height.

Raised position (B) is recommended for straw crops with tall stubble and soft ground conditions.

• Recommended with bale ramp.
• Pickup teeth will not touch the ground with pickup completely lowered.

A-Normal Position
B-Raised Position

AG,OUO6017,1424 -19-06OCT99-1/1
