Duble/Single Acting SCV’s Conversion

AGCPTJD0085
AGCPTJD0085-UN-21MAY13

The spool valves are fitted with a square drive screw (M) for conversion between double and single acting

Unscrew the screw until the mechanical stop is felt.

To use a spool valve in single acting mode, connect the implement’s hose to the left hand outlet.
