ROPS in Normal Position

LX205082-UN-14NOV13

CAUTION: Avoid crushing injury or death during rollover. Use Foldable ROPS and Seat Belt Properly. If this machine is equipped with a foldable roll-over protective structure (ROPS), keep the ROPS in the fully extended and locked position. USE a seat belt when you operate with a ROPS in the fully extended position.

• Hold the latch and pull the seat belt across the body.
• Insert the latch into the buckle. Listen for a click.
• Tug on the seat belt to make sure that the belt is securely fastened.
• Snug the seat belt across the hips.

CAUTION: If this machine is operated with the ROPS folded (e.g., to enter a low building), drive with extreme caution. DO NOT USE a seat belt with the ROPS folded. Return the ROPS to the raised, fully extended position as soon as the machine is operated under normal conditions.
