MW/FM/LW Home Page on the CommandCenter™

RXA0122016-UN-04NOV11

FM Home Page

A - Scan Softkey

B - Seek Forward/Back Softkeys ¹

C - Band Softkey

D - Auto Store Softkey

E - Select Source Softkey

F - Audio Settings Softkey

G - Volume Adjustment

H - Presets 1—6

I - FM Tabs 1-3

J - Display Area 1

K - Display Area 2

Select SCAN softkey (A) will scan available radio stations and pause for 8 seconds before moving on to the next station. To cycle through channels use Seek Forward/Back softkeys (B). Six presets can be programmed in the Preset Stations softkeys for each band (i.e. FM1, FM2, FMT). Auto Store softkey (D) allows the operator to store the 6 strongest frequencies in the FMT band by pressing the Auto Store softkey. Stored frequency then appears in presets. To change a preset, select and hold the preset for 3 seconds. Two banks of presets are available or FM home page. Cycle through the banks using the tabs (I).

Band softkey (C) allows operator to cycle through radio tuner sources (FM, and any other sources available to radio in your area. The Select Source softkey (E) allows operator the ability to cycle through radio tuner sources and external source (see Radio Source Select on the CommandCenter™ in this section).

In Display Area 1 (J) artist name and song name will be visible if available from the radio station. In Display Area 2 (K) channel number, preset number and station name will be visible.
