Prepare Machine for Storage

Repair worn or damaged parts. Install new parts, if necessary, to avoid needless delays later.

Clean primary air cleaner element.

MR64971,00000C2 -19-05DEC01-1/3

IMPORTANT: High pressure washing, greater than 1379 kPa (200 psi) can damage freshly painted finishes. Paint should be allowed to air dry for 30 days minimum after receipt of machine before cleaning parts or machine with high pressure. Use low pressure wash operations until 30 days have elapsed.

Wash the machine. Paint areas to prevent rust. Replace decals, where needed.

Apply waste oil to track chains. Run machine back and forth several times. Park machine on a hard surface to prevent tracks from freezing to ground.

IMPORTANT: LPS ® 3 R Rust Inhibitor can destroy painted finish. DO NOT spray LPS 3 Rust Inhibitor on painted surfaces.

Retract all hydraulic cylinders, if possible. If not, coat exposed cylinder rods with LPS ® 3 Rust Inhibitor.

Store machine in a dry, protected place. If stored outside, cover with a waterproof material.

LPS is a registered trademark of the Holt Lloyd Corporation.

MR64971,00000C2 -19-05DEC01-2/3

IMPORTANT: Prevent possible machine damage from unauthorized persons operating machine. Attach a "DO NOT OPERATE" tag to steering wheel.

Move battery disconnect switch to OFF position.

Lubricate all grease points.

Remove batteries.

Remove all perishable items.

Remove keys and lock all covers and doors.

MR64971,00000C2 -19-05DEC01-3/3
