Roll Hardware Decal

NOTE: Decal (A) is located on left- and right-hand side of machine.

(A) - Important Damage to baler or roller can result from improper torque setting. Torque 16 mm roller bolts to 350 N·m (250 lb.-ft.).

PP98408,0000328 -19-28OCT09-1/1
