High Engine Coolant Temperature Indicator

Red light on and buzzer pulses. Stop engine and check:

• Radiator coolant level
• Plugged radiator or rotary screen leaking hoses
• Broken fan belt
• Correct engine fan speed (See SERVICE ENGINE section)

If the light still stays on, see your John Deere dealer.

OUO6075,000281B -19-17MAR03-1/1
