Turn Signals

When operating combine on road or highway, use turn signals.

NOTE: The turn signals operate anytime the ignition key is "ON" and the Field Light switch is "OFF". When the field light switch is "ON" the turn signal lever operates the side finder lights. The turn signals are not self-cancelling so the lever must be move back to the neutral position.

With light switch lever on (hazard or road position), warning light flashers will operate at 60 flashes per minute. When turn signal is set for right-hand turn, the right-hand warning light will flash 90 flashes per minute while the left-hand warning light stays on (not flashing). The opposite happens for the left-hand turn.

NOTE: The indicator light on the steering column glows steadily and indicates a turn.
