Abnormal Voltage Indicator

NOTE: Yellow indicator light may come ON if engine was started with low batteries.

When yellow indicator light comes ON a problem exists with the voltage system. When voltage drops below 10 volts, indicator light will come ON and buzzer will sound four times. Indicator remains ON and buzzer sounds four times every five minutes until voltage is above 11 volts.

NOTE: Indicator light will dim and buzzer volume will decrease as voltage lowers.

Check wiring, alternator belt, batteries and cables for possible problems. If light stays ON, see your John Deere dealer.

OUO6075,000057D -19-06SEP06-1/1
