Batteries—Connecting Booster
H96584-UN-24MAY10
A - Positive (+) Post
B - Negative (-) Post
Cold weather starting can be easier by connecting an additional 12-volt battery in parallel.
CAUTION: Gas given off by batteries is explosive. Avoid sparks near batteries.
IMPORTANT: Never connect jumper cables with key switch ON. Never jump-start with more than 12 volts.
Remove protective caps from posts.
First jumper cable must first be connected to positive (+) post of booster battery. Connect other end to positive (+) post (A) of machine battery. Second jumper cable must first be connected to negative (-) post of booster battery. Connect other end to negative (-) post (B) of machine battery.
OUO6075,000077D-19-20100524 |
