Check Tires For Damage And Correct Inflation Pressure—Daily

TS211-UN-23AUG88

Tire Pressure For Machines with Liquid System Installed
Tank Liquid		Direct Injection	Tire Size	Tire Pressure	Max. Allowable Axle Weight
Water	Fertilizer
X			380/105R50	440 kPa (64 psi)	11,200 kg (24,600 lbs)
X			IF380/105R50	380 kPa (55 psi)	11,200 kg (24,600 lbs)
X			480/80R50	380 kPa (55 psi)	11,200 kg (24,600 lbs)
X			620/70R46	260 kPa (38 psi)	11,200 kg (24,600 lbs)
X		X	380/105R50	440 kPa (64 psi)	11,200 kg (24,600 lbs)
X		X	IF380/105R50	420 kPa (61 psi)	13,000 kg (28,600 lbs)
X		X	480/80R50	380 kPa (55 psi)	11,200 kg (24,600 lbs)
X		X	620/70R46	260 kPa (38 psi)	11,200 kg (24,600 lbs)
	X		380/105R50	440 kPa (64 psi)	11,200 kg (24,600 lbs)
	X		IF380/105R50	420 kPa (61 psi)	13,000 kg (28,600 lbs)
	X		480/80R50	400 kPa (58 psi)	11,600 kg (25,600 lbs)
	X		620/70R46	283 kPa (41 psi)	11,600 kg (25,600 lbs)
	X	X	380/105R50	440 kPa (64 psi)1	11,200 kg (24,600 lbs)
	X	X	IF380/105R50	480 kPa (67 psi)	13,800 kg (30,400 lbs)
	X	X	480/80R50	440 kPa (64 psi)	12,300 kg (27,200 lbs)
	X	X	620/70R46	300 kPa (44 psi)	12,300 kg (27,200 lbs)

Tire Pressure with Dry Spreader Installed
Tire Size	Tire Pressure	Max. Allowable Axle Weight
380/105R50	Not Recommended	Not Recommended
IF380/105R50	460 kPa (67 psi)	14,200 kg (31,400 lbs)
480/80R50	500 kPa (73 psi)	14,200 kg (31,400 lbs)
620/70R46	380 kPa (55 psi)	14,200 kg (31,400 lbs)

CAUTION: Explosive separation of a tire and rim parts can cause serious injury or death. Do not attempt to mount a tire unless you have the proper equipment and experience to perform the job.

Always maintain the correct tire pressure. Do not inflate the tires above the recommended pressure. Never weld or heat a wheel and tire assembly. The heat can cause an increase in air pressure resulting in a tire explosion. Welding can structurally weaken or deform the wheel.

When inflating tires, use a clip-on chuck and extension hose long enough to allow you to stand to one side and NOT in front of or over the tire assembly. Use a safety cage if available.

Check wheels for low pressure, cuts, bubbles, damaged rims, or missing lug bolts and nuts.

Protect tires from exposure to sunlight, petroleum products and chemicals.

Try to avoid rocks and sharp objects; drive carefully.

Traveling at high speeds while carrying heavy loads will increase tire wear and reduce tire life.
