Lubricate Nurse Arm—Every Season

IMPORTANT: Use ONLY John Deere SD Polyurea grease (TY6341).

IMPORTANT:

N83582
N83582-UN-08OCT09

Lubricate nurse arm grease points at the beginning and end of every season.

  1. N83597
    N83597-UN-20MAR09

    Lubricate grease fittings on boom arm, nurse coupler mount, and lift arms.


  2. N82579
    N82579-UN-12DEC08

    Lubricate boom arm and bottom lift arm grease fitting.


  3. N82428
    N82428-UN-12DEC08

    Lubricate top lift arm grease fitting.

OUO6041,000025A-19-20090409
