Check Tires Daily For Damage And Correct Inflation Pressure—Daily
CAUTION:
TS211-UN-15APR13
Always maintain the correct tire pressure. Do not inflate the tires above the recommended pressure. Never weld or heat a wheel and tire assembly. The heat can cause an increase in air pressure resulting in a tire explosion. Welding can structurally weaken or deform the wheel.
When inflating tires, use a clip-on chuck and extension hose long enough to allow you to stand to one side and NOT in front of or over the tire assembly. Use a safety cage if available.
Check wheels for missing bolts and nuts, reduced tire pressure, cuts, bubbles, or rim damage.
Protect tires from exposure to petroleum products and chemicals as well as from direct sunlight during storage.
Try to avoid rocks and sharp objects; drive carefully.
Traveling at high speeds while carrying heavy loads will increase tire wear and reduce tire life.
|
R4030 Recommended Tire Inflation Pressure |
|||||
|---|---|---|---|---|---|
|
Tire Size |
Wet System |
Dry System |
|||
|
27.4 /30.4 M (90/100 ft.) without Direct Injection (DI) |
27.4 /30.4 M (90/100 ft.) with Direct Injection |
36.6 M (120 ft.) without DI |
36.6 M (120 ft.) with DI |
200 cubic foot Spreader |
|
|
IF320/90R50 - 161D1 |
441 kPa (64 psi) |
441 kPa (64 psi) |
441 kPa (64 psi) |
441 kPa (64 psi) |
441 kPa (64 psi) |
|
IF320/105R46 - 166D |
421 kPa (61 psi) |
441 kPa (64 psi) |
441 kPa (64 psi) |
462 kPa (67 psi) |
421 kPa (61 psi) |
|
VF380/90R46 - 173D |
248 kPa (36 psi) |
283 kPa (41 psi) |
283 kPa (41 psi) |
303 kPa (44 psi) |
248 kPa (36 psi) |
|
IF380/90R46 - 168D |
338 kPa (49 psi) |
379 kPa (55 psi) |
379 kPa (55 psi) |
400 kPa (58 psi) |
338 kPa (49 psi) |
|
380/90R46 - High Capacity - 168A8/B |
427 kPa (62 psi) |
441 kPa (64 psi) |
441 kPa (64 psi) |
462 kPa (67 psi) |
462 kPa (67 psi) |
|
380/90R46 - Standard Capacity - 163A8/B |
427 kPa (62 psi) |
441 kPa (64 psi) |
441 kPa (64 psi) |
462 kPa (67 psi) |
462 kPa (67 psi) |
|
IF420/80R46 - 167D |
303 kPa (44 psi) |
338 kPa (49 psi) |
338 kPa (49 psi) |
358 kPa (52 psi) |
303 kPa (44 psi) |
|
520/85R38 - 169A8/B |
248 kPa (36 psi) |
269 kPa (39 psi) |
269 kPa (39 psi) |
289 kPa (42 psi) |
276 kPa (40 psi) |
|
620/70R38 - 170A8/B |
207 kPa (30 psi) |
221 kPa (32 psi) |
221 kPa (32 psi) |
241 kPa (35 psi) |
241 kPa (35 psi) |
|
650/65R38 - 166D |
186 kPa (27 psi) |
214 kPa (31 psi) |
200 kPa (29 psi) |
228 kPa (33 psi) |
207 kPa (30 psi) |
|
R4038 Recommended Tire Inflation Pressure |
|||||
|---|---|---|---|---|---|
|
Tire Size |
Wet System |
Dry System |
|||
|
27.4 /30.4 M (90/100 ft.) without Direct Injection (DI) |
27.4 /30.4 M (90/100 ft.) with Direct Injection |
36.6 M (120 ft.) without DI |
36.6 M (120 ft.) with DI |
200 cubic foot Spreader |
|
|
IF320/105R46 - 166D |
462 kPa (67 psi) |
483 kPa (70 psi) |
483 kPa (70 psi) |
483 kPa (70 psi) |
421 kPa (61 psi) |
|
VF380/90R46 -173D |
317 kPa (46 psi) |
338 kPa (49 psi) |
338 kPa (49 psi) |
358 kPa (52 psi) |
248 kPa (36 psi) |
|
IF380/90R46 - 168D |
400 kPa (58 psi) |
441 kPa (64 psi) |
441 kPa (64 psi) |
462 kPa (67 psi) |
338 kPa (49 psi) |
|
IF420/80R46 - 167D |
379 kPa (55 psi) |
400 kPa (58 psi) |
400 kPa (58 psi) |
420 kPa (61 psi) |
303 kPa (44 psi) |
|
520/85R38 - 169A8 / B |
310 kPa (45 psi) |
338 kPa (49 psi) |
338 kPa (49 psi) |
358 kPa (52 psi) |
276 kPa (40 psi) |
|
620/70R38 - 170A8/B |
290 kPa (42 psi) |
310 kPa (45 psi) |
310 kPa (45 psi) |
330 kPa (48 psi) |
241 kPa (35 psi) |
|
650/65R38 - 166D1 |
269 kPa (39 psi) |
283 kPa (41 psi) |
283 kPa (41 psi) |
283 kPa (41 psi) |
221 kPa (32 psi) |
|
R4045 Recommended Tire Inflation Pressure |
||||||
|---|---|---|---|---|---|---|
|
Tire Size |
Wet System |
Dry System |
||||
|
27.4 /30.4 M (90/100 ft.) without Direct Injection (DI) |
27.4 /30.4 M (90/100 ft.) with Direct Injection |
36.6 M (120 ft.) without DI |
36.6 M (120 ft.) with DI |
200 cubic foot Spreader |
300 cubic foot Spreader |
|
|
IF380/105R50 - 177D |
427 kPa (62 psi) |
455 kPa (66 psi) |
441 kPa (64 psi) |
469 kPa (68 psi) |
359 kPa (52 psi) |
441 kPa (64 psi) |
|
VF420/95R50 |
310 kPa (45 psi) |
331 kPa (48 psi) |
331 kPa (48 psi) |
352 kPa (51 psi) |
276 kPa (40 psi) |
324 kPa (47 psi) |
|
480/80R50 - 176A8/B |
448 kPa (65 psi) |
469 kPa (68 psi) |
462 kPa (67 psi) |
476 kPa (69 psi) |
414 kPa (60 psi) |
469 kPa (68 psi) |
|
620/70R46 - 176A8/B |
283 kPa (41 psi) |
296 kPa (43 psi) |
289 kPa (42 psi) |
303 kPa (44 psi) |
283 kPa (41 psi) |
345 kPa (50 psi) |
|
710/60R46 - 178D |
207 kPa (30 psi) |
241 kPa (35 psi) |
221 kPa (32 psi) |
255 kPa (37 psi) |
193 kPa (28 psi) |
228 kPa (33 psi) |
|
710/65R46 - 183D |
193 kPa (28 psi) |
228 kPa (33 psi) |
200 kPa (29 psi) |
241 kPa (35 psi) |
172 kPa (25 psi) |
207 kPa (30 psi) |
|
IF800/55R46 - 175D |
186 kPa (27 psi) |
200 kPa (29 psi) |
193 kPa (28 psi) |
207 kPa (30 psi) |
262 kPa (38 psi) |
186 kPa (27 psi) |
|
1 Full condition
may exceed recommended load or speed for tire.
|
OUO6092,000094D-19-20150402 |
