Check Air Filter Hose

Inspect air intake system hoses and connections each time the air filter is changed, or at a minimum yearly.

1. Park machine safely.

2. Raise hood.

3. Visually inspect hose for cracks and wear. Squeeze hose to check for deterioration. Hose should not be hard and brittle, nor soft or swollen.


   LV27284-UN-17JAN17

   A - Air Filter Hose

   C - Hose Clamp

   Check air filter hose (A).

---




4. Tighten hose clamps (B) if necessary.

5. Lower hood.
