Inspecting Driveline CV Boots

1. Park the vehicle safely. (See Parking Safely in the SAFETY section.)

2.
   MXAL44252-UN-10APR13

   Viewed from under the machine.

   Inspect four rear CV boots (A) for tears or punctures.

---




3. Inspect four front CV boots (B) for tears or punctures. Repeat for opposite side of machine.

4. Inspect rear drive shaft boot (C) for tears or punctures.

5. If replacement of a boot is necessary, see your John Deere dealer.
