Resetting Standards

CAUTION: Standards can strike persons too close during tripping or resetting, resulting in serious injury or death to you or others. Stay clear of standards when operating.

Stay clear of reset path of standards when they are in a partially tripped position.

To reset safety-trip standard after it has tripped, raise V-Ripper into transport position and standard will return to working position.

To reset shear bolt standard, raise V-Ripper into transport position. Install new shear bolt.

The spring-reset rock standard will reset automatically.

AG,OUO1011,1352 -19-28SEP99-1/1
