Transporting Machine
Reduce speed when turning. Do not uncouple tractor brake pedals and apply tractor brakes individually in an attempt to make a shorter turn. Serious injury or death can result from contact with electric lines. Use care when moving or operating machine near electric lines to avoid contact. Know transport height and machine width. Check local regulations before transporting. (See Specifications section for transport height and machine width.) Transport with wings fully folded. Never raise or lower wings when moving. After folding, ALWAYS place wing-fold lever in NEUTRAL position for transport. If wing-fold cylinders are removed, chain wings together to prevent serious injury or death caused by accidental falling of wings. Machine is hitch light when equipped with 3-bar spike-tooth harrow with rolling baskets. Upward force on hitch may cause instability when transporting. Add ballast to tractor as required to maintain stability. |
|
CAUTION:
When transporting machine on a smooth surface road, do not exceed maximum transport speed of 32 km/h (20 mph). Reduce speed considerably when traveling over rough ground.
NX,980L99,A7BZ -19-14APR99-1/1 |
