Transporting Machine

causym CAUTION: When transporting machine on a smooth surface road, do not exceed maximum transport speed of 32 km/h (20 mph). Reduce speed considerably when traveling over rough ground.

Reduce speed when turning. Do not uncouple tractor brake pedals and apply tractor brakes individually in an attempt to make a shorter turn.

Serious injury or death can result from contact with electric lines. Use care when moving machine near electric lines to avoid contact. Know the transport height of your machine. See SPECIFICATIONS section for transport height of your machine.

Transport with wings fully folded. Never raise or lower wings when moving. After folding, ALWAYS place wing-fold lever in neutral position, for transport. Know the transport width of your machine. See SPECIFICATIONS section for transport width of your machine.

If wing-fold cylinders are removed, chain wings together to prevent injury or death caused by accidental falling of wings on you or others.

N39084
N39394

AG,OUO1011,2678 -19-29MAR00-1/1
