Cleaning Radiator

1. Remove side screen and brush debris from radiator, oil cooler and air conditioning condenser (A).

causym CAUTION: Condenser core is heavy and WILL fall when latch is released which can cause serious injury to you or others. Support condenser core adequately when unlatching.

2. Pull out latch to clean between radiator and oil cooler condenser. Pivot condenser rearward carefully.


A-Condenser

TS286
N42132FY

AG,OUO1011,1207 -19-09SEP99-1/1
