Gang Press Attachment
|
|
The gang press attachment is designed for firming the soil over the seed. 51 mm or 102 mm (2 in. or 4 in.) press wheels are designed to follow the furrow openers over heavy or light soil conditions. The gang is raised when the openers are raised, and lowered |
when the openers are lowered. This makes it possible to back the machine when necessary and transport with gang raised off the ground. For adjustment, see Operating The Machine section. |
AG,OUO6074,979 -19-09MAY00-1/1 |
