Shim Locations for 6.6 m (21 ft 9 in.) Narrow
|
|
IMPORTANT: Install shims at front outer joints and rear inner joints on each wing as |
shown. Use 3/4 x 3 in. cap screws at these locations. |
| Number of Shims Installed at Front Outer Joint | Number of Shims Installed at Rear Inner Joint | |
|---|---|---|
| With Harrow | Without Harrow | |
| 3 | 2 | 2 |
AG,OUO1011,947 -19-16AUG99-1/1 |
