C-Spring Locations
|
NXH8,Y63755,K31 -19-06JUL98-1/2 |
T-Taper C-Spring
R-Regular C-Spring
| Front Main | Rear Main | Front Wing | Rear Wing | |||||||||||||||
| Size m (ft-in.) |
#1 | #2 | #3 | #4 | #1 | #2 | #3 | #1 | #2 | #3 | #4 | #5 | #6 | #1 | #2 | #3 | #4 | #5 |
| 3.7 (12-2) | T | R | - | - | R | R | - | - | - | - | - | - | - | - | - | - | - | - |
| 4.1 (13-7) | T | R | R | - | R | R | - | - | - | - | - | - | - | - | - | - | - | - |
| 4.6 (15) | T | R | R | - | R | R | R | - | - | - | - | - | - | - | - | - | - | - |
| 5.5 (17-11) | T | R | R | - | T | T | - | R | R | - | - | - | - | R | R | - | - | - |
| 6.3 (20-9) | T | R | R | - | T | T | - | T | R | - | - | - | - | R | R | - | - | - |
| 6.5 (21-4) | T | R | R | - | T | T | - | T | R | - | - | - | - | R | R | - | - | - |
| 6.8 (22-2) | T | R | R | - | T | T | - | T | R | - | - | - | - | R | R | - | - | - |
| 7.2 (23-7) | T | R | R | - | T | T | - | T | R | R | - | - | - | R | R | R | - | - |
| 8 (26-5) | T | R | R | - | T | T | - | T | R | R | - | - | - | R | R | R | - | - |
| 8.1 (26-7) | T | R | R | - | T | T | - | T | R | R | - | - | - | R | R | R | - | - |
| 8.9 (29-3) | R | R | R | T | T | T | - | T | R | R | - | - | - | T | R | R | - | - |
| 9.7 (31-10) | R | R | R | T | T | T | - | T | R | R | R | - | - | T | T | T | - | - |
| 9.8 (32-1) | R | R | R | T | T | T | - | T | R | R | R | - | - | T | R | R | R | - |
| 10.6 (35) | R | R | R | T | T | T | - | T | R | R | R | R | - | T | R | R | R | - |
| 10.8 (35-4) | R | R | R | T | T | T | - | T | R | R | R | R | - | T | T | T | T | - |
| 11.5 (37-10) | R | R | R | T | T | T | - | T | R | R | R | R | R | T | R | R | R | R |
