Checking Wing Fold Operation

causym CAUTION: To help prevent severe injury or death to you or someone else:

Make sure air has been properly bled from wing-fold hydraulic system.

Keep all persons away from machine when raising and lowering wings.

Always locate machine on level ground when raising and lowering wings.

Never raise or lower wings when moving.

IMPORTANT: 5-SECTION MACHINES ONLY- 7-Pin plug MUST BE ATTACHED in order for wings to unfold and fold. WINGS WILL NOT UNFOLD without 7-pin plug attached. There must also be 12 volts from 7-plug at tractor in order for wings to unfold. (See TROUBLESHOOTING 5-SECTION MACHINE WING-FOLDING OPERATION in Troubleshooting Section.)

5-SECTION MACHINES ONLY- In order for wings to be folded and unfolded, set SCV II selector button flow control knob to fast (rabbit) position and verify tractor is running at 1800 rpm.

5-SECTION MACHINES WITH ROLLING BASKETS- Wings should NOT fold or unfold with rolling baskets raised. Folding or unfolding wings with rolling baskets raised will cause machine damage.

1. Place tractor transmission in "park" and/or set brakes, then start engine and pull back on SCV II tractor control lever (A) to retract wing fold cylinders.

N39547
N79562
N48108

8000 Series Tractor


A-SCV II Tractor Control Lever

KB78086,00003C5 -19-14MAY08-1/2

2. Move SCV II tractor control lever back and forth several times while observing operation of machine. Wings should raise when lever is pulled back and lower when lever is pushed forward. If action is reversed, reverse hose connections in SCV II hydraulic coupler.

If wing fold does not operate smoothly, air may be trapped in cylinders or hoses. Refer to INSTALLING AND BLEEDING WING FOLD CYLINDERS in SERVICE section. If after bleeding, machine still does not operate properly, see your John Deere dealer.

3. After attaching and cycling cylinders, check tractor hydraulic oil reservoir. Add oil if necessary.

KB78086,00003C5 -19-14MAY08-2/2
