Clean Air Conditioning Condenser/Hydraulic Oil Cooler -As Required

CAUTION: Reduce compressed air to 210 kPa (2 bar) (30 psi) or less when using for cleaning purposes. Clear area of bystanders, guard against flying debris, and wear personnel protection equipment, including eye protection.

CAUTION: Always wear eye protection when cleaning with compressed air. A filter type respirator is also advised to avoid inhalation of harmful particles.

1. Stop engine and clean front grille and side panels using a brush.

2. Remove engine side shields and remove any trash built up on radiator and cooler-condenser.

3. Remove front grille screen brace on each side of cooler-condenser. Slide cooler-condenser partially out one side, clean and repeat process for the other side. Use compressed air at no more than 210 kPa (2 bar) (30 psi) (A) or water. Straighten any bent fins.

A-Compressed Air

AG,OUO1011,925 -19-27JUL99-1/1
