Planetary Hub Oil

Use oil viscosity based on the expected air temperature range during the period between oil changes.

The following oil is preferred:

• John Deere SYNTHETIC OIL (TY24777)

NOTE: Planetary hubs are filled with John Deere SYNTHETIC OIL (TY2477) from the factory.

NX,HYD,2 -19-13JAN99-1/1
