SETTINGS softkey

IMPORTANT: To reprogram to another language, language being selected needs to be on data card. If language file does not load properly, reload software to data card.

NOTE: If vehicle loses battery power or if display is disconnected from vehicle Time and Date Settings will have to be reset.

The Settings screen contains three tabs:

REGIONAL tab

Country, Language, Numeric Format and Units can be selected. Use drop-down boxes and select desired measurements to be displayed on screen.

TIME AND DATE tab

Date and time can be changed, as well as time format. GPS Sync can be selected to automatically set the time using the time data coming from GPS receiver. When this is selected, user should choose proper time offset, which adjusted the GPS time data to correspond to your time zone, to ensure correct local time. Time Sync will not occur until GPS signal is acquired.

UNITS OF MEASURE tab

Users can customize units for a mix of metric and imperial units.

OUO6092,0000D42 -19-07DEC06-1/1
