Check Tires Daily For Damage And Correct Inflation Pressure—Daily

TS211-UN-23AUG88

4730 Tires
Tires/Air Pressure	kPa	bar	psi
320/90R46	399.9	4.0	58
320/90R50 (Brazil Only)	537.8	5.38	78
380/90R46 (Firestone)	324	3.24	47
380/90R46 (Michelin)	317	3.17	46
420/80R46	303.4	3.03	44
520/85R38	206.8	2.07	30

4830 Tires
Tires/Air Pressure	kPa	bar	psi
320/90R50	537.8	5.38	78
380/90R46	427	4.28	62
380/90R46 (Goodyear)	427	4.28	62
380/90R46 (Michelin)	372	3.72	54
420/80R46	414	4.14	60
600/65R38	283	2.83	41

CAUTION: Explosive separation of a tire and rim parts can cause serious injury or death. Do not attempt to mount a tire unless you have the proper equipment and experience to perform the job.

Always maintain the correct tire pressure. Do not inflate the tires above the recommended pressure. Never weld or heat a wheel and tire assembly. The heat can cause an increase in air pressure resulting in a tire explosion. Welding can structurally weaken or deform the wheel.

When inflating tires, use a clip-on chuck and extension hose long enough to allow you to stand to one side and NOT in front of or over the tire assembly. Use a safety cage if available.

Check wheels for low pressure, cuts, bubbles, damaged rims or missing lug bolts and nuts.

Protect tires from exposure to sunlight, petroleum products and chemicals.

Try to avoid rocks and sharp objects; drive carefully.

Traveling at high speeds while carrying heavy loads will increase tire wear and reduce tire life.
