Check Tires Daily For Damage And Correct Inflation Pressure—Daily

TS211-UN-15APR13

R4030 Recommended Tire Inflation Pressure
Tire Size	Wet System				Dry System
	27.4 /30.4 M (90/100 ft.) without Direct Injection (DI)	27.4 /30.4 M (90/100 ft.) with Direct Injection	36.5 M (120 ft.) without DI	36.5 M (120 ft.) with DI	200 cubic foot Spreader
IF320/90R50 - 161D1	441 kPa (64 psi)	441 kPa (64 psi)	441 kPa (64 psi)	441 kPa (64 psi)	441 kPa (64 psi)
VF380/90R46 - 173D	248 kPa (36 psi)	283 kPa (41 psi)	283 kPa (41 psi)	303 kPa (44 psi)	248 kPa (36 psi)
IF380/90R46 - 168D	338 kPa (49 psi)	379 kPa (55 psi)	379 kPa (55 psi)	400 kPa (58 psi)	338 kPa (49 psi)
380/90R46 - Hi Capacity - 168A8/B	427 kPa (62 psi)	441 kPa (64 psi)	441 kPa (64 psi)	462 kPa (67 psi)	462 kPa (67 psi)
380/90R46 - Standard Capacity - 163A8/B	427 kPa (62 psi)	441 kPa (64 psi)	441 kPa (64 psi)	462 kPa (67 psi)	462 kPa (67 psi)
IF420/80R46 - 167D	303 kPa (44 psi)	338 kPa (49 psi)	338 kPa (49 psi)	358 kPa (52 psi)	303 kPa (44 psi)
520/85R38 - 169A8/B	248 kPa (36 psi)	269 kPa (39 psi)	269 kPa (39 psi)	289 kPa (42 psi)	276 kPa (40 psi)
620/70R38 - 170A8/B	207 kPa (30 psi)	221 kPa (32 psi)	221 kPa (32 psi)	241 kPa (35 psi)	241 kPa (35 psi)

R4038 Recommended Tire Inflation Pressure
Tire Size	Wet System				Dry System
	27.4 /30.4 M (90/100 ft.) without Direct Injection (DI)	27.4 /30.4 M (90/100 ft.) with Direct Injection	36.5 M (120 ft.) without DI	36.5 M (120 ft.) with DI	200 cubic foot Spreader
VF380/90R46 -173D	317 kPa (46 psi)	338 kPa (49 psi)	338 kPa (49 psi)	358 kPa (52 psi)	248 kPa (36 psi)
IF380/90R46 - 168D	400 kPa (58 psi)	441 kPa (64 psi)	441 kPa (64 psi)	462 kPa (67 psi)	338 kPa (49 psi)
IF420/80R46 - 167D	379 kPa (55 psi)	400 kPa (58 psi)	400 kPa (58 psi)	420 kPa (61 psi)	303 kPa (44 psi)
520/85R38 - 169A8 / B	310 kPa (45 psi)	338 kPa (49 psi)	338 kPa (49 psi)	358 kPa (52 psi)	276 kPa (40 psi)
620/70R38 - 170A8/B	290 kPa (42 psi)	310 kPa (45 psi)	310 kPa (45 psi)	330 kPa (48 psi)	241 kPa (35 psi)

CAUTION: Explosive separation of a tire and rim parts can cause serious injury or death. Do not attempt to mount a tire unless you have the proper equipment and experience to perform the job.

Always maintain the correct tire pressure. Do not inflate the tires above the recommended pressure. Never weld or heat a wheel and tire assembly. The heat can cause an increase in air pressure resulting in a tire explosion. Welding can structurally weaken or deform the wheel.

When inflating tires, use a clip-on chuck and extension hose long enough to allow you to stand to one side and NOT in front of or over the tire assembly. Use a safety cage if available.

Check wheels for low pressure, cuts, bubbles, damaged rims or missing lug bolts and nuts.

Protect tires from exposure to sunlight, petroleum products and chemicals.

Try to avoid rocks and sharp objects; drive carefully.

Traveling at high speeds while carrying heavy loads will increase tire wear and reduce tire life.
