Lift Bar Decals

N80954-UN-16JUN08

Lift Bar

SSN317012-UN-19JUN08

Decal A

Warning! Avoid serious injury or death resulting from crushing during solution tank skid and dry box removal and installation.

1. Use only for John Deere 4 Series sprayer solution tank skid and dry box.
2. Empty application system prior to installation and removal processes.
3. Stay clear of application system during installation and removal processes.
4. Follow instructions included with lift bar.

SSN317056-UN-19JUN08

Decal B

SSN317016-UN-19JUN08

Decal C

Decal B—

IMPORTANT: Torque each bolt to 200 lb-ft (271 N·m). Retorque before each time of use and after each time bolts are loosened.

Decal C—

To rear of machine

N106668-UN-18SEP13

Decal D

4030 Lift Bar Adjustment Without DI		4030 Lift Bar Adjustment With DI
Boom Size	Dimension (B)	Boom Size	Dimension (B)
27.4 m (90 ft.)	873 mm (34 in.)	27.4 m (90 ft.)	827 mm (33 in.)
30.5 m (100 ft.)	907 mm (36 in.)	30.5 m (100 ft.)	863 mm (34 in.)
36.6 m (120 ft.)	1259 mm(50 in.)	36.6 m (120 ft.)	1241 mm (49 in.)
Dry Spreader	(See New Leader installation instructions.)	Dry Spreader	(See New Leader installation instructions.)

4030 POLY TANK Lift Bar Adjustment Without DI		4030 POLY TANK Lift Bar Adjustment With DI
Boom Size	Dimension (B)	Boom Size	Dimension (B)
27.4 m (90 ft.)	851 mm (34 in.)	27.4 m (90 ft.)	795 mm (31 in.)
30.5 m (100 ft.)	888 mm (35 in.)	30.5 m (100 ft.)	830 mm (33 in.)
36.6 m (120 ft.)	1253 mm (49 in.)	36.6 m (120 ft.)	1221 mm (48 in.)
Dry Spreader	(See New Leader installation instructions.)	Dry Spreader	(See New Leader installation instructions.)

4038 Lift Bar Adjustment Without DI		4038 Lift Bar Adjustment With DI
Boom Size	Dimension (B)	Boom Size	Dimension (B)
27.4 m (90 ft.)	891 mm (35 in.)	27.4 m (90 ft.)	844 mm (33 in.)
30.5 m (100 ft.)	925 mm (36 in.)	30.5 m (100 ft.)	876 mm (34 in.)
36.6 m (120 ft.)	1275 mm (50 in.)	36.6 m (120 ft.)	1249 mm (49 in.)
Dry Spreader	(See New Leader installation instructions.)	Dry Spreader	(See New Leader installation instructions.)
