Fill Solution Tank with Nurse Tank Pump

1. CAUTION: Read carefully the directions printed on the chemical manufacturer's labels before handling chemicals exposure to hazardous materials could poison and injure you.

   IMPORTANT: Do not add chemical to solution tank until just before field use. Follow the chemical manufacturer's instructions for mixing the spray solution to obtain the desired application rate and effect.

   CAUTION: Quik-Fill valve (A) can contain hazardous materials which can poison causing serious injury or death to you or others. Before removing Quik-Fill cap (B), Verify Quik-Fill valve is closed.


   N99947-UN-11JUL13

   Side Quik-Fill


   N94524-UN-17SEP12

   A - Quik-Fill Valve

   B - Cap

   C - Push-On Fill Button

   Verify Quik-Fill valve (A) is closed.

---




2. Open lock levers and remove cap (B).

3. Connect nurse tank fill hose to Quik-Fill adapter, close lock levers, and open nurse tank valve.

4. NOTE: Automatic fill is not active when filling with nurse pump.

   Press push-on fill button (C), open Quik-Fill valve, fill using nurse pump.

5. After solution tank has filled to desired level, shut down nurse tank pump and close nurse tank valve.

6. Close Quik-Fill valve and press push-on fill button to close solution tank sump valve.

7. Remove fill hose from Quik-Fill adapter and replace cap.
