Bleeding the Fuel System (Electric Fuel Transfer Pump)1. Remove plug and install RE193349 fitting (A) into filter header.2. Connect output hose of priming pump to fitting (A) in filter header. 3. Install input hose into container of fuel. Place fuel container higher than fuel pump for better priming results. 4. Connect power wire to positive terminal (B) on alternator with switch off and find a clean ground point for ground connection. NOTE: Open fuel shut-off valve prior to bleeding the fuel system.
|
|
T803324,000056A -19-10FEB05-1/1 |
