Reset Switch (Quick Reset Switch)

When starting the harvester, all harvesting functions are disabled and the Harvesting Function Stop Switch lights up. The operator has to turn the Harvesting Function Reset Switch off, then back on to start all harvesting functions. If the engine is turned off or engine dies, the harvesting function reset switch will have to be turned off and back on again to restart the harvesting functions.

OU64006,0000166 -19-22FEB08-1/1
