DIAGNOSTIC softkey

The StarFire iTC - Diagnostic screen contains three tabs:

READINGS tab

DATA LOGS tab

RADIO SELF TEST tab

READINGS tab has detailed information about receiver.

• Unswitched voltage
• Switched voltage
• CAN High voltage (Vehicle Bus)
• CAN Low voltage (Vehicle Bus)
• Software Part Number
• Software Version Number
• Hardware Part Number
• Hardware Serial Number
• Receiver Hours (h)

The following reading will only appear when receiver has a RTK activation.

• RTK Software Number (RTK Radio Software Version)
• RTK Serial Number (RTK Radio Serial Number)
• RTK Status
• RTK Search Time (sec)
• RTK Satellites in Search (above 7 degrees elevation)

DATA LOGS tab has graphed GPS data, logged over the previous 60 minutes.

JS56696,00005A9 -19-13MAY09-1/1
